AISI 1060 Steel Bar

  • Introduction

Steels containing carbon as the main alloying element are called carbon steels. They contain up to 0.4% silicon and 1.2% manganese. Residual elements such as copper, molybdenum, aluminium, chromium and nickel may also be present in these steels.AISI 1060 carbon steel has characteristics similar to that of AISI 1055 carbon steel.


  • Application

1060 plate is a carbon steel that is widely used in wear rail and other applications where flame hardening, for surface hardness, is commonly used. 1060 plate is spheroidized annealed which is ideal for subsequent machining, forming, quench-and-temper heat treatment and flame hardening.


  • Chemical composition and Physical properties Of 1060 steel

      Chemical composition:

 Element

Content (%)

Iron, Fe

98.35-98.85

Manganese, Mn

0.60-0.90

Carbon, C

0.55-0.660

Sulfur, S

≤ 0.050

Phosphorous, P

≤ 0.040


      Physical properties  :

 Properties

Metric

Imperial

Density

7.85 g/cm3

0.284 lb/in3

Melting point

1510ºC

2750ºF


  •   Other Analysis

     Mechanical Properties:

Properties

Metric

Imperial

Tensile strength, ultimate

620 MPa

89900 psi

Tensile strength, yield

485 MPa

70300 psi

Modulus of elasticity

190-210 GPa

29700-30458 ksi

Bulk modulus (typical for steel)

140 GPa

20300 ksi

Shear modulus (typical for steel)

80 GPa

11600 ksi

Poissons ratio

0.27-0.30

0.27-0.30

Elongation at break (in 50 mm)

10%

10%

Reduction of area

45%

45%

Hardness, Brinell

183

183

Hardness, Knoop (converted from Brinell hardness)

204

204

Hardness, Rockwell B (converted from Brinell hardness)

89

89

Hardness, Vickers (converted from Brinell hardness)

192

192



     Thermal Properties:

Properties

Metric

Imperial

Thermal expansion co-efficient

11 µm/m°C

6.11 µin/in°F

Thermal conductivity

49.8 W/mK

346 BTU in/hr.ft2.°F
